DJI Osmo Mobile 8 Smart Phone Stabilizer

Key Specifications

• Extension Rod: Built-in Extension Rod, Max Extension Length: 215 mm
• Compatible Phone Weight: 170-300 g
• Compatible Phone Thickness:9-10 mm
• Compatible Phone Width: 67-84 mm
• Bottom Port: 1/4″-20 UNC port

Battery

• Type: Li-Po 1S
• Capacity: 3350 mAh
• Energy:06 Wh
• Charging Temperature: 5° to 40° C (41° to 104° F)
• Operating Temperature: 0° to 40° C (32° to 104° F)
• Operating Time: Approx. 10 hours
  (Measured with the gimbal balanced in a level and stationary state without additional accessories)
• Charging Time: 2.5 hours
  (Measured with a 10W USB-C charger)
• Gimbal Charging Port: USB-C
• Phone Charging: Supported

Gimbal

Controllable Range

• Pan: 360° (unlimited rotation)
• Roll: -67° to 245°
• Tilt: -20° to 40°

Mechanical Range

• Pan: 360° (unlimited rotation)
• Roll: -77° to 255°
• Tilt: -224° to 100°

Max Control Speed: 120°/s

Wireless Mode

• Model: Bluetooth 5.3

Software

• App: DJI Mimo



Multifunctional Module

• GFSK: 2 Mbps
• GFSK Transmitter Power (EIRP): < 16 dBm
• GFSK Operating Frequency:2.4000-2.4835 GHz
•    Bluetooth Protocol: Bluetooth 5.3
• Bluetooth Transmitter Power (EIRP): < 16 dBm
• Bluetooth Operating Frequency: 4000-2.4835 GHz
• Fill Light Illuminance: 40 lux

Dimensions

• Unfolded: 288×107×96 mm (L×W×H)
• Folded: 190×95×46 mm (L×W×H)

·         Weight

• Gimbal + Built-in Tripod + Magnetic Phone Clamp + Multifunctional Module: Approx. 370 g

Tripod

Dimensions

• Built-in Tripod
• Length: 67 mm
