TP-Link Archer VR300 is an AC1200 Wireless VDSL/ADSL

Wireless Performance

• Dual-Band Wi-Fi: Supports simultaneous 2.4GHz (300 Mbps) and 5GHz (867 Mbps) connections, totaling up to 1200 Mbps.
• Wireless Standards: IEEE 802.11a/n/ac (5GHz), IEEE 802.11b/g/n (2.4GHz).
• Antennas: Equipped with four fixed external antennas to enhance wireless coverage and stability.
• Transmit Power: 2.4GHz <20dBm(EIRP), 5GHz <23dBm(EIRP).
• Wireless Functions: Supports Access Point and Wireless Bridge modes, with options to enable/disable wireless functionality and SSID broadcast.
• Wireless Security: Offers WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, and Quick Security Setup (QSS) via WPS.

Hardware Specifications

Interfaces:

• 3 × 10/100 Mbps RJ45 LAN Ports
• 1 × 10/100 Mbps RJ45 LAN/WAN Port
• 1 × RJ11 DSL Port

Buttons: WPS, Power On/Off, and Reset.

Power Supply: 12V/1A.

Dimensions: 385 × 290 × 76 mm.

DSL Standards:

VDSL2: Supports ITU G.993.2 (up to 17a profile), G.993.5 (G.vector), and G.998.4 (G.INP).

ADSL/ADSL2/ADSL2+: Compatible with full-rate ANSI T1.413 Issue 2, ITU-T G.992.1 (G.DMT), G.992.2 (G.Lite), G.994.1 (G.hs), G.995.1, G.992.3 (G.DMT.bis), G.992.4 (G.lite.bis), and G.992.5.

Software Features

Operating Modes: Functions as both a VDSL/ADSL Modem Router and a Wireless Router.

Quality of Service (QoS): Supports ATM QoS and Bandwidth Control.

Security: Includes NAT Firewall, Access Control, and IP/MAC Address Binding.

Management:

• Web-based configuration (HTTP).
• Remote management capabilities.
• Command Line Interface (CLI).
• SSL for TR-069.
• SNMP v1/2c.
• Web-based firmware upgrade.
• Diagnostic tools.

DHCP: Supports DHCP Server, Client, Client List, Address Reservation, and DHCP Relay.

Port Forwarding: Features Virtual Server, Port Triggering, DMZ, ALG, and UPnP.

Dynamic DNS: Compatible with DynDns and NO-IP services.

VPN Pass-Through: Supports PPTP, L2TP, and IPSec Passthrough.

Protocols: Supports both IPv4 and IPv6.

ATM/PPP Protocols: Includes ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER/IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), and supports up to 8 PVCs.

Advanced Functions: Offers Parental Control, Network Address Translation (NAT), Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS, and IGMP V1/V2/V3.

Guest Network: Provides separate 2.4GHz and 5GHz guest networks.
